6.2KW 48000BPH Carbonated Beverage Filling Machine Isobaric

Product Categories

Automatic Water Bottle Filling Machine [345]
5 Gallon Water Filling Machine [152]
Glass Bottle Filling Machine [31]
Juice Filling Machine [74]
Carbonated Drink Filling Machine [66]
Aluminum Can Filling Machine [26]
Blowing Mould Machine [22]
Reverse Osmosis Water Filtration System [22]
Shrink Sleeve Label Machine [18]
Bottle Sticker Labeling Machine [19]
OPP Labeling Machine [10]
Carton Box Packing Machine [12]
Shrink Film Wrapping Machine [13]
Date Code Printing Machine [13]

zhangjiagang aquatrin Machinery co.,ltd

Contact Now

6.2KW 48000BPH Carbonated Beverage Filling Machine Isobaric

Name: 62KW 48000BPH Carbonated Beverage Filling Machine Isobaric
Brand: Aquatrin
Price: 15000 USD

Quality 6.2KW 48000BPH Carbonated Beverage Filling Machine Isobaric wholesale

Brand Name : Aquatrin

Model Number : DGCF

Certification : ISO CE SGS

Place of Origin : China

MOQ : 1unit

Price : USD15000-60000 1Set

Payment Terms : T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Condition : New

Warranty : 2 years

Filling speed : 6000-48000BPH

Filling range : 100-1000ml

Usage : Beverage Filling Packaging

Name : carbonated beverage filling machine

Contact Now

Technical Parameters
Model	DCGF12-12-5	DCGF18-18-6	DCGF24-24-8	DCGF32-32-10
Capacity (500ml)(B/H)	2000-3000	3000-5000	5000-7000	7000-10000
Filling way	isobaric filling
Filling temperature (℃ )	0-5℃
Bottle height	160-320mm
PET bottle specification	Bottle diameter 50-115mm,Height160-320mm
Suitable cap shape	Plastic screw cap
Total power	4.4	5.2	6.2	6.2
Overall dimensions	225016502250	260019652250	298022002250	388022002250
Weight(kg)	2500	3500	4500	6000

6.2KW 48000BPH Carbonated Beverage Filling Machine Isobaric

carbonated drink filling machine

6.2KW 48000BPH Carbonated Beverage Filling Machine Isobaric

Auxiliary Equipment

Water Treatment System.


1 Raw water tank + Raw water pump
 2 Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter
 3 Reverse Osmosis (one level)
 4 UV sterilizer
 5 Finished water tank + Pure water pump
Drink Mixing Machine
 1. Suitable beverage types: Cola and lemon.
 2. Mixing ratio range: 3:1 - 6:1
 3. CO2 content: 4 times
 4. Volume: CO2 consumption of about 4 M3/h
 5. CO2 supply pressure: 0.8-1 Mpa
 6. CO2 Purity: 99.9%
 7. Consumption of ethylene glycol solution: water=30M3/h
 8. Ethylene glycol solution pressure: 1.0Mpa
 9. Ethylene glycol solution inlet temperature: -2
 Shower Cooling Machine.
Automatic Labeling Machine

Bottle Packaging Machine.
Bottle blowing machine

We provide free bottle design
we provide free layout design
